FEATURES
軽さ、安定性、美しさを兼ね備えた、真のオールラウンダー。
最先端の空力設計とPanama SLハブを搭載し、1,376gという驚異的な軽さを実現。
2:1スポーク比(21本)が、あらゆる路面状況で優れた安定性としなやかな反応性を提供します。
外観は、伝説的ギターFrankenstratからインスピレーションを得た独自のスタイル。
レーザーエッチングロゴが、高級感とミニマルな美しさを演出します。
レースからロングライドまで。すべてをこの1本で。
SPECS
General |
Rim |
Hub |
Spoke |
Weight (±3%) 1,376g |
Material 100% Carbon Fiber |
Model PANAMA SL |
Model SAPIM CX-RAY AERO |
Front / Rear Weight 628g / 748g |
Height 45mm |
Type Straight Pull |
Front / Rear Count 21 (2:1 ratio) / 21 (2:1 ratio) |
Brake Type Disc Brake |
Rim size (ETRTO) 700C / 28″ |
Brake Interface Center Look |
Material Stainless |
Tubeless Ready(TLR) Yes |
External Width 30mm |
Axle System 12 x 100 / 12 x 142 mm |
Spoke type Straight Pull Aero |
Clincher (Inner Tubes) Yes |
Internal Width 21mm |
Free Hub System 36T Star ratchet |
Spoke length*(Front) DS 263mm / NDS 262mm |
Race-Ready UCI approved |
Recommended tire width 26-32C |
Compatibility Shimano/SRAM/Campagnolo |
Spoke length*(Rear) DS 261mm / NDS 254mm |
Maximum Rider Weight 130kg |
Minimum tire width 23C |
Bearings(Front) 2 x Enduro |
Nipples SAPIM Black / alloy, internal adjust |
Maximum tire width 36C |
Bearings(Rear) 2 x Enduro / 2 x SKF |
Spoke tension*(Front) DS 880-980Nm / NDS 900-1080Nm |
|
Spoke tension*(Rear) DS 980-1180Nm / NDS 880-980Nm * DS = Disc Side, NDS = Non Disc Side |
