FEATURES
軽量・空力性能・妥協なき設計
クラシックロード向けに最適化された全く新しい Genus CL45-R は、革新的なエアロ性能と高い剛性、美しいデザインを兼ね備えています。
そしてまた、わずか1,339g(セット)という驚異的な軽さをも実現しました。
新開発のPanama SLハブと、2:1組みで1輪あたり21本のAeris PLTカーボンスポークを採用し、抜群の安定性と耐久性を提供します。
レーザーエッチングによるロゴと、エディ・ヴァン・ヘイレンのギターにインスパイアされたラインデザインが、あらゆるバイクに洗練された存在感を与えます。
Genus CL45-R — 軽さと性能、美しさを求めるライダーに最適なアップグレード。
SPECS
General |
Rim |
Hub |
Spoke |
Weight (±3%) 1,339g |
Material 100% Carbon Fiber |
Model PANAMA SL |
Model SAPIM AERO CARBON |
Front / Rear Weight 603g / 736g |
Height 45mm |
Type Straight Pull |
Front / Rear Count 21 (2:1 ratio) / 21 (2:1 ratio) |
Brake Type Disc Brake |
Rim size (ETRTO) 700C / 28″ |
Brake Interface Center Look |
Material Carbon |
Tubeless Ready(TLR) Yes |
External Width 30mm |
Axle System 12 x 100 / 12 x 142 mm |
Spoke type Straight Pull Aero |
Clincher (Inner Tubes) Yes |
Internal Width 21mm |
Free Hub System 36T Star ratchet |
Spoke length*(Front) DS 271mm / NDS 270mm |
Race-Ready UCI approved |
Recommended tire width 26-32C |
Compatibility Shimano/SRAM/Campagnolo |
Spoke length*(Rear) DS 268mm / NDS 262mm |
Maximum Rider Weight 130kg |
Minimum tire width 23C |
Bearings(Front) 2 x Enduro |
Nipples SAPIM Black / alloy, internal adjust |
Maximum tire width 36C |
Bearings(Rear) 2 x Enduro / 2 x SKF |
Spoke tension*(Front) DS 780-980Nm / NDS 900-1080Nm |
|
Spoke tension*(Rear) DS 1080-1280Nm / NDS 900-1080Nm * DS = Disc Side, NDS = Non Disc Side |
